Cold finishing center of excellence for automotive component manufacturing.
Products
| TYPE | DIAMETER |
|---|---|
| Peeling, burnishing (Bars)* | Ø 13 - 83mm, up to tolerance band h9 |
| Grinding (Bars)* | Ø 10 - 80mm up to tolerance band h8 (h7 for Ø < 30mm on demand) |
| Finished/semi finished parts | |
| • Sawing, chanfering (Bars) | Ø 15 - 80mm, length 2,500 - 10,000mm |
| • Sawing (Slug)* | Ø 10 to 105mm, length 30mm to 2,000mm, chamfering machine, center hole, threading, marking |
| • Sawing, grinding (Slug) | Ø 18 - 30mm up to tolerance band h7, length 350 - 1,000mm |
| * Feasible on tubes | |
Finishing equipments
- Peeling: Kieserling lathes, Calow;
- Cutting to length: Ohler saw;
- Centerless grinding: Lidköping, R4B;
- Sawing and machining: Wagner, Rattunde;
- Controls: surface defects (eddy-current, MPI),
anti-mix, dimensional controls.
Certifications
ISO 9001 • IATF 16949 • ISO 14001 • ISO 45001 and ISO 50001
